4.4 Clearing Paper Jams

4-12

4.4

Clearing Paper Jams

If the paper jammed in the paper transport system, or no paper sheets were fed at all, the
Paper jam

message appears and the location of the paper jam (the component where the

paper jam has occurred) is also indicated. The printer automatically goes off-line when this
message is displayed. Remove jammed paper. After removing jammed paper, the printer
will re-start printing.

4.4.1

Possible Paper Jam Locations

The figure below explains the printer’s paper paths including the options, for example, the
document finisher and the duplexer (a standard accessory for the FS-C8008DN). The
locations where paper jams might occur are also shown here, with each location explained
in

Table 4-7

below. Paper jams can occur in more than one component on the paper paths.

Figure 4-1
