48” Mower Deck - Housing & Arbor Group
63 TP 400-2218-00-SV-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1691219 48” Mower Deck
1691221 48” Mower Deck
1693418 48” Mower Deck
1693419 48” Mower Deck
1 923471 3 CAPSCREW, Hex Hd., 7/16-14 x 1-1/4
2 1918199 3 LOCKWASHER, 7/16
3 1933263 3 WASHER, 29/64 x 1-1/4 x 1/4
4 1679157 1 PULLEY ASSEMBLY
5 1657969 3 SHIELD, Bearing, Upper
6 1655729 3 HOUSING, Arbor, Top
7 108202 6 BEARING
8 1679194 1 SHAFT.Arbor, Center
9 1703273 3 HOUSING, Arbor Bottom
10 1916964 4 LOCKWASHER, 1/4
11 1916622 4 NUT, Hex, Full, 1/4-20
12 1679161 2 PULLEY ASSEMBLY, Deck Drive
13 1676277 2 SHAFT, Arbor, Side (Incl. Ref. No. 15, Qty. 1)
14 1664847 18 CAPSCREW, Hex Washer Hd, Taptite, 5/16-18 x 3/4
15 1657528 3 RING, Self-Locking
16 1931333 4 CARRIAGE BOLT, 5/16-18 x 3/4
17 108454 1 BRACKET & SHAFT ASSEMBLY
18 1668513 2 ROLLER
19 1960020 2 WASHER, 21/32
20 1918458 2 PIN, Cotter
21 108224 1 BRACKET, Roller, L.H.
22 1916950 6 NUT, Hex, Full, 3/8-16
23 1916965 6 LOCKWASHER 3/8
24 1931350 2 CARRIAGE BOLT, 3/8-16 x 1
25 1917372 4 NUT, Hex, Full, 5/16-18
26 1917356 4 LOCKWASHER, 5/16
27 1674774 1 BAFFLE, 48” Mower
27 1675587 1 BAFFLE, 42” Mower
28 1921959 2 CAPSCREW, Hex Hd, 1/4-20 x 5/8
29 1925592 2 CAPSCREW, Thread Forming, 1/4-20 x 3/4
30 108186 2 CLIP,. Baffle
31 1921319 2 WASHER, Plain, 9/32
32 1960268 4 CARRIAGE BOLT, 3/8-16 x 1-1/4
33 108366 1 BAR, Reinforcement
34 108219 2 BRACKET ASSEMBLY, Front
35 1685281 1 HOUSING, 42” Mower (Orange)
35 1685282 1 HOUSING, 48” Mower (Orange)
35 61685281 1 HOUSING, 42” Mower (Black)
35 61685282 1 HOUSING, 48” Mower (Black)
36 1679195 1 SHAFT & BEARING ASSEMBLY, Center (Incl. Ref. Nos. 7 & 8).
37 1676278 2 SHAFT & BEARING ASSEMBLY, Side (Incl. Ref. Nos. 7 & 13)
38 1924940 4 WASHER, 13/32 I.D.
39 1707335 3 GASKET, Foam
40 1704314 3 FITTING, Grease
