Hydrostatic pump group – Simplicity SOVEREIGN TP 400-2218-00-SV-SMA User Manual
Page 21
The above parts group applies to the following Mfg. Nos.:
1692796
Sov 18HP Hydro
1692798
Sov 18HP Hydro PS
1692845
918H, 18HP Hydro
1692847
918H, 18HP Hydro PS
1692849
2818H 18HP Hydro
1692852
2818H, 18HP Hydro PS
1692889
Sov 75 Anv 18HP OHC Hydro
1692943
Sov 18HP OHC Hydro PS
1692945
Sov 18HP OHC Hydro
1692949
918H, 18HP OHC Hydro PS
1692951
918H, 18HP OHC Hydro
1692953
2818H, 18HP OHC Hydro PS
1692955
2818H, 18HP OHC Hydro
1693144
Sov 18HP OHC Hydro-Exp
1693146
Sov 18HP OHC Hydro PS-Exp
1693148
Sov 75 Anv 18HP OHC-Exp
1693407
Sov 18HP OHC Hydro PS
1693409
Sov 18HP OHC Hydro
1693411
918H, 18HP OHC Hydro PS
1693413
918H, 18HP OHC Hydro
1693415
2818H, 18HP OHC Hydro PS
1693417
2818H, 18HP OHC Hydro
19
TP 400-2218-00-SV-SMA
REF NO.
PART NO.
QTY.
DESCRIPTION
Footnotes:
Hydrostatic Pump Group
1
1923735
4
CAPSCREW, Self-Tapping, #10-3/8
2
178779
1
DEFLECTOR, Shroud
3
1921332
1
CAPSCREW, Hex Hd, 5/16-18 x 3/4
4
1919326
4
WASHER, Plain, 5/16
5
1917356
2
LOCKWASHER, 5/16
6
1917372
1
NUT, Hex, Full, 5/16-18
7
166022
1
FAN, Pulley
8
1671582
1
HYDRO PUMP, (see pages 18 - 21 for service parts)
9
1650633
1
PLATE, Spacer
10
1916965
3
LOCKWASHER, 3/8
11
1925695
3
CAPSCREW, Hex Hd, 3/8-16 x 5
12
1650524
1
SPACER
13
1921333
2
CAPSCREW, Hex Hd, 5/16-18 x 1
14
1651089
1
BRACKET
15
1651090
1
LATCH, Release
16
153010
1
SPRING
17
1923362
1
LOCKNUT, Hex, 5/16-18
18
1960103
2
WASHER
19
1671229
1
HOSE, Inlet
20
930709
2
CLAMP, Hose
21
1671228
2
ELBOW, Hose Fitting 45°
22
1666415
1
SHROUD ASSEMBLY, w/Screen
23
1664847
1
CAPSCREW, Hex Washer Hd, Taptite, 5/16-18 x 3/4
24
1651703
1
O-RING
25
166003
1
PINION, Motor Shaft
26
1933468
1
WASHER
27
1709322
1
FILTER ASSEMBLY
28
1927428
3
CAPSCREW, Hex Hd, Taptite, 1/4-20 x 3/8
