Dash, Hood & Grille Group - Manual Steering Models

39

TP 400-2218-00-SV-SMA

REF NO.

PART NO.

QTY.

DESCRIPTION

Footnotes:

The above parts group applies to the following Mfg. Nos.:

1692798

Sov 18HP Hydro PS

1692847

918H, 18HP Hydro PS

1692852

2818H, 18HP Hydro PS

1692943

Sov 18HP OHC Hydro PS

1692949

918H, 18HP OHC Hydro PS

1692953

2818H, 18HP OHC Hydro PS

1693146

Sov 18HP OHC Hydro PS-Exp

1693407

Sov 18HP OHC Hydro PS

1693411

918H, 18HP OHC Hydro PS

1693415

2818H, 18HP OHC Hydro PS

1

1926025

6

CAPSCREW, Machine, Round Hd, 1/4-20 x 1/2 (Manual Steering Models

Only)

2

172008

1

PLATE, Adjusting, Steering (Manual Steering Models Only)

3

157077

1

BUSHING (Manual Steering Models Only)

4

1651000

1

PANEL, Instrument (Manual Steering Models)

5

1917867

6

SPEED NUT, Tinnerman

6

1713844

1

KNOB

7

1713848

1

HANDLE, Throttle Control

8

101025

1

WASHER

9

960171

1

WASHER

10

1930531

1

CAPSCREW, Truss Hd, #10-32 x 1/2

11

1685408

1

DASH ASSEMBLY

12

1930561

9

CAPSCREW, Hex, Self-Tapping, #14AB x 3/4

13

1928703

6

NUT, Speed

14

158475

1

CLIP, Control Cable (All Except 1692796, 1692845, & 1692849)

14

1709060

1

CLIP, Control Cable (1692796, 1692845, & 1692849 Only)

15

1930665

1

LOCKWASHER, Dished Type, 3/8

16

1928919

1

NUT, Hex, Washer, #10-32

17

1666703

1

ARM, Throttle

18

103280

2

STOP, Throttle

19

159107

1

WASHER

20

1930651

1

LOCKNUT, Hex, 3/8-16 (All Except 1692889 & 1693148)

21

177447

1

PLUG, Button

22

1933988

2

PUSH NUT

23

1931333

2

CARRIAGE BOLT, 5/16-18 x 3/4

24

1708749

1

HOOD & GRILLE ASSEMBLY, Orange (All Except 1692889 & 1693148)

24

41708749

1

HOOD & GRILLE ASSEMBLY, Red (All Except 1692889 & 1693148)

25

1666163

1

MOULDING, Hood

26

1930531

2

CAPSCREW, Truss Hd, #10-32 x 1/2

27

1930627

2

LOCKNUT, Hex, #10-32

28

1960096

2

WASHER, Special

29

171600

2

STRAP, Hood

30

1666148

1

SCREEN

31

1960517

10

LOCKNUT, Pal

32

1921210

2

CAPSCREW, Hex Hd, 3/8-16 x 1 (All Except 1692889 & 1693148)

33

1930651

2

LOCKNUT, Hex, 3/8-16

34

1675932

4

CLIP, Headlight Mounting (All Except 1692889 & 1693148)
