Electrical Group - Early Models
35 TP 400-2218-00-SV-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* Not serviced separately.
The above parts group applies to the following Mfg. Nos.:
1692796 Sov 18HP Hydro
1692798 Sov 18HP Hydro PS
1692845 918H, 18HP Hydro
1692847 918H, 18HP Hydro PS
1692849 2818H 18HP Hydro
1692852 2818H, 18HP Hydro PS
1 1685058 1 BATTERY, Incl. decal,
2 1713534 1 INSULATOR, Battery Terminal
3 1708730 1 CABLE, Battery to Solenoid
4 1917356 2 LOCKWASHER, 5/16
5 1920263 2 NUT, Hex, 5/16-24
6 1916622 3 NUT, Hex, Full, 1/4-20
7 1916964 4 LOCKWASHER, 1/4
8 1603189 1 AMMETER
9 1686637 1 IGNITION SWITCH KIT (Incl. Ref. Nos. 10, 11, 12 & 13)
10 1714054 1 KEY
11 1714055 1 NUT, Adapter
12 1960547 1 LOCKWASHER, Int., 5/8
13 * 1 SWITCH, Ignition
14 122184 1 SWITCH, Toggle
15 171225 1 CLAMP
16 1714647 1 CABLE (Battery to Ground)
17 1708734 1 HARNESS ASSEMBLY
18 1925125 1 WASHER, 15/32
19 177522 1 SWITCH, Interlock, Ball
20 1930647 1 NUT, Pal
21 1926192 1 WASHER, 9/16
22 1932771 1 CLIP, Cable
23 1717970 1 GROMMET, Rubber
24 172434 4 CLIP, Tinnerman
25 172436 3 CLIP, Tinnerman
26 1674358 1 WIRE ASSEMBLY
27 1713535 1 INSULATOR, Terminal Boot
28 1674363 2 HEADLIGHT ASSEMBLY
29 1707755 1 MODULE, Interlock
30 * 2 REFLECTOR, Housing
31 1960433 1 NUT, Hex Flange, M8 - 125
32 1677368 2 LENS, Clear
33 1665238 1 BREAKER, Circuit
34 1923341 2 CAPSCREW, Hex Hd, 1/4-20 x 3/4
35 1704379 1 SWITCH, Interlock, Seat
36 1677370 1 SOCKET, Bulb
37 1685290 1 SOLENOID, Starter
38 1919438 2 NUT, Elastic, 5/16-18
39 1918199 1 LOCKWASHER, 7/16
40 932747 3 TIE
41 1921319 3 WASHER, Special, 1/4
42 934683 4 CLIP, Wire
43 165073 1 CLIP, Speed Cable
44 1677371 1 BULB
45 1917415 1 NUT, Hex, #10-32
46 1922711 1 LOCKWASHER, Ext. Tooth
47 1920676 1 CAPSCREW, Hex Hd, 7/16-14 x 1
48 1701229 1 BUSHING, Snap
