Simplicity SOVEREIGN TP 400-2218-00-SV-SMA - Manual (Page 15)

The above parts group applies to the following Mfg. Nos.:
1692889 Sov 75 Anv 18HP OHC Hydro
1692943 Sov 18HP OHC Hydro PS
1692945 Sov 18HP OHC Hydro
1692949 918H, 18HP OHC Hydro PS
1692951 918H, 18HP OHC Hydro
1692953 2818H, 18HP OHC Hydro PS
1692955 2818H, 18HP OHC Hydro
1693144 Sov 18HP OHC Hydro-Exp
1693146 Sov 18HP OHC Hydro PS-Exp
1693148 Sov 75 Anv 18HP OHC-Exp
1693407 Sov 18HP OHC Hydro PS
1693409 Sov 18HP OHC Hydro
1693411 918H, 18HP OHC Hydro PS
1693413 918H, 18HP OHC Hydro
1693415 2818H, 18HP OHC Hydro PS
1693417 2818H, 18HP OHC Hydro
13 TP 400-2218-00-SV-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
* See an authorized Kohler Dealer for service parts.
Engine, Exhaust & Drive Shaft Group — Kohler 18HP OHC
1 172744 2 STRAP, Rubber, Fuel Tank
2 1666275 1 TANK ASSEMBLY, Fuel
3 171252 1 CAP, Fuel Tank
4 171330 2 STRAP, Tank
5 1654930 1 BUSHING
6 1664460 1 FITTING
7 1717551 1 HOSE, Fuel, 15”
8 1960112 2 CLAMP, Hose
9 1701011 1 TIE, Cable, 7.3” Lg.
10 1708405 1 VALVE, Shut Off
11 166137 1 HOSE, Hydraulic, 1/2 ID x 3/4 x 12
12 1678371 1 CONTROL, Throttle
13 1708764 1 CONTROL, Choke
14 1960475 1 SETSCREW, 3/8-24 x 3/8
15 157427 1 KEY, Drive Shaft, 3/16 x 1-1/4
16 172264 1 FLANGE, Drive Shaft
17 1916950 7 NUT, Hex, Full, 3/8-16
18 1916965 10 LOCKWASHER, 3/8
19 157424 18 WASHER, Special
20 173026 2 COUPLING
21 1920415 8 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
22 1717111 1 DRIVE SHAFT ASSEMBLY
23 1930598 3 CAPSCREW, Hex Washer Hd, Taptite, 3/8-16 x 1.5
24 1932771 1 CLIP
25 1716896 1 PLATE, Engine
26 920426 1 LOCKWASHER, Ext. Tooth, 3/8
27 1708761 1 ELBOW PIPE, Exhaust (All except 1692889 & 1693148)
28 1712286 1 CLAMP, Exhaust (Qty 2 on 1692889 & 1693148)
29 1716898 1 MUFFLER, Exhaust
30 1924856 1 CAPSCREW, Hex Hd, Taptite, 5/16-18 x 1/2
31 1708873 1 HEAT SHIELD, Muffler
32 1713337 2 PAD, Neoprene (Power Steering Models Only)
33 * 1 ENGINE, Kohler, 18HP OHC
33 * 1 ENGINE, Kohler, 18HP OHC, 75th Anniversary Model
