Seat & Deck Group - Later Models
45 TP 400-2218-00-SV-SMA
1 1718851 1 SEAT
2 1709307 1 SUPPORT, Seat Pivot
3 1931339 2 CARRIAGE BOLT, 5/16 -16 x 2” Lg
4 172434 1 CLIP, Speed
5 1663752 2 SPACER
6 1924940 2 WASHER, Plain
7 1919439 2 NUT, Hex Nylon Lock, 3/8-16
8 1931350 2 CARRIAGE BOLT, 3/8-16 x 1
9 1928352 2 NUT, Hex Flange, Whiz Lock, 3/8-16
10 1718858 1 BRACKET, Seat Pivot
11 1704299 2 SPACER
12 1709308 2 SPRING, Compression
13 1707101 1 PLATE, Switch
14 1704728 2 SPRING, Compression (2” OD)
15 1709256 2 WASHER, Seat Spring
16 1919438 2 NUT, Hex Nylon Lock, 5/16-18
17 1704724 2 COVER, Spring
18 1701229 1 BUSHING, Snap
19 1930651 2 NUT, Hex Lock, 3/8-16
20 1607870 1 STOP, Seat Deck
21 1920415 2 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
22 1715769 1 DECK ASSEMBLY, Seat (Orange)
22 41715769 1 DECK ASSEMBLY, Seat (Red)
23 1917372 8 NUT, Hex, Full, 5/16-18
24 1917356 8 LOCKWASHER, 5/16
25 164029 1 BRACKET, Front Seat Deck
26 1708361 1 PLATE, Reinforcement
27 1960459 2 CAPSCREW, Truss Head, Torx Drive, 3/8-16 x 1
28 1919326 8 WASHER, 11/32
29 1666744 2 CONNECTOR, Cushion
30 1606823 2 CLIP, Latch
31 1925205 2 CAPSCREW, Hex Hd, 5/16-18 x 5/8
32 1931648 4 CAPSCREW, Hex Flange Hd, Whiz Lock, 5/16-18 x 1/2
33 1707137 1 SPRING, Extension
34 1714441 1 SLIDE, Seat
35 1704723 1 GRIP, Lever
36 1718859 1 LEVER, Seat Release
37 1960020 2 WASHER, 5/8 x 1-1/4 x 1/16
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693407 Sov 18HP OHC Hydro PS
1693409 Sov 18HP OHC Hydro
1693411 918H, 18HP OHC Hydro PS
1693413 918H, 18HP OHC Hydro
1693415 2818H, 18HP OHC Hydro PS
1693417 2818H, 18HP OHC Hydro
