Electrical Group - Later Models
37 TP 400-2218-00-SV-SMA
REF NO. PART NO. QTY. DESCRIPTION
The above parts group applies to the following Mfg. Nos.:
1692889 Sov 75 Anv 18HP OHC Hydro
1692943 Sov 18HP OHC Hydro PS
1692945 Sov 18HP OHC Hydro
1692949 918H, 18HP OHC Hydro PS
1692951 918H, 18HP OHC Hydro
1692953 2818H, 18HP OHC Hydro PS
1692955 2818H, 18HP OHC Hydro
1693144 Sov 18HP OHC Hydro-Exp
1693146 Sov 18HP OHC Hydro PS-Exp
1693148 Sov 75 Anv 18HP OHC-Exp
1693407 Sov 18HP OHC Hydro PS
1693409 Sov 18HP OHC Hydro
1693411 918H, 18HP OHC Hydro PS
1693413 918H, 18HP OHC Hydro
1693415 2818H, 18HP OHC Hydro PS
1693417 2818H, 18HP OHC Hydro
1 1685058 1 BATTERY, Incl. decal,
2 1713534 1 INSULATOR, Battery Terminal
3 1665235 1 CABLE, Battery to Solenoid
4 1917356 2 LOCKWASHER, 5/16
5 1920263 2 NUT, Hex, 5/16-24
6 1916622 4 NUT, Hex, Full, 1/4-20
7 1916964 4 LOCKWASHER, 1/4
8 1603189 1 AMMETER
9 1686637 1 IGNITION SWITCH KIT (Incl. Ref. Nos. 10, 11, 12 & 13)
10 1714054 1 KEY
11 1714055 1 NUT, Adapter
12 1960547 1 LOCKWASHER, Int., 5/8
13 * 1 SWITCH, Ignition
14 122184 1 SWITCH, Toggle (All except 1692889 & 1693148)
14 1717406 1 SWITCH, Toggle (1692889 & 1693148 Only)
15 171225 1 CLAMP
16 1714647 1 CABLE (Battery to Ground)
17 1717183 1 HARNESS ASSEMBLY
18 1925125 1 WASHER, 15/32
19 177522 1 SWITCH, Interlock, Ball
20 1930647 1 NUT, Pal
21 1926192 1 WASHER, 9/16
22 1932771 4 CLIP, Cable
23 1703851 1 CABLE, Starter to Solenoid
24 172434 4 CLIP, Tinnerman
25 172436 3 CLIP, Tinnerman
26 1674358 1 WIRE ASSEMBLY (All except 1692889 & 1693148)
26 1717238 1 WIRE ASSEMBLY, Headlight (1692889 & 1693148 Only)
27 1713535 1 INSULATOR, Terminal Boot
28 1674363 2 HEADLIGHT ASSEMBLY (Incl. Ref. Nos. 30, 32, 36 & 44) (All except
1692889 & 1693148)
29 1707755 1 MODULE, Interlock
30 * 2 REFLECTOR, Housing (All except 1692889 & 1693148)
31 ** 1 NUT, Hex
32 1677368 2 LENS, Clear (All except 1692889 & 1693148)
33 1665238 1 BREAKER, Circuit
34 1923341 2 CAPSCREW, Hex Hd, 1/4-20 x 3/4
35 1704379 1 SWITCH, Interlock, Seat (All except 1692889 & 1693148)
36 1677370 1 SOCKET, Bulb (All except 1692889 & 1693148)
37 1685290 1 SOLENOID, Starter
38 1919438 2 NUT, Elastic, 5/16-18
39 1918199 1 LOCKWASHER, 7/16
40 932747 3 TIE
41 1921319 2 WASHER, Special, 1/4
42 934683 4 CLIP, Wire
43 165073 1 CLIP, Speed Cable
44 1677371 1 BULB (All except 1692889 & 1693148)
45 1917415 1 NUT, Hex, #10-32
46 1922711 1 LOCKWASHER, Ext. Tooth
47 1920676 1 CAPSCREW, Hex Hd, 7/16-14 x 1
48 1701229 1 BUSHING, Snap
49 122023 1 COVER, Terminal, Solenoid
50 172996 1 ADAPTOR, Wire Terminal
51 1665237 1 WIRE ASSEMBLY, Solenoid to Circuit Breaker
52 1717409 1 WIRE, Jumper, Headlight Switch (1692889 & 1693148 Only)
Footnotes:
* Not Serviced Separately ** Supplied by Engine Manufacturer
