The above parts group applies to the following Mfg. Nos.:
1692796 Sov 18HP Hydro
1692798 Sov 18HP Hydro PS
1692845 918H, 18HP Hydro
1692847 918H, 18HP Hydro PS
1692849 2818H 18HP Hydro
1692852 2818H, 18HP Hydro PS
1692889 Sov 75 Anv 18HP OHC Hydro
1692943 Sov 18HP OHC Hydro PS
1692945 Sov 18HP OHC Hydro
1692949 918H, 18HP OHC Hydro PS
1692951 918H, 18HP OHC Hydro
1692953 2818H, 18HP OHC Hydro PS
1692955 2818H, 18HP OHC Hydro
1693144 Sov 18HP OHC Hydro-Exp
1693146 Sov 18HP OHC Hydro PS-Exp
1693148 Sov 75 Anv 18HP OHC-Exp
1693407 Sov 18HP OHC Hydro PS
1693409 Sov 18HP OHC Hydro
1693411 918H, 18HP OHC Hydro PS
1693413 918H, 18HP OHC Hydro
1693415 2818H, 18HP OHC Hydro PS
1693417 2818H, 18HP OHC Hydro
27 TP 400-2218-00-SV-SMA
REF NO. PART NO. QTY. DESCRIPTION
Hydraulic Lift Group
1 1667408 2 HOSE, Hydraulic
2 172320 1 FITTING, Elbow, 45°
3 1960033 2 CLIP, Hairpin
4 919766 1 CONNECTOR, 37° Male
5 171690 2 PIN
6 1685347 1 CYLINDER (Includes Fitting, Ref. No. 2)
7 928812 2 ELBOW, Adjustable, 37°
8 1928731 1 LOCKNUT, Hex, Jam, 3/8-16
9 174723 2 GUARD, Cable
10 157081 1 SPACER
11 172725 1 PULLEY
12 1708298 2 PIN
13 1918196 1 CLIP, Spring
14 1960106 1 CAPSCREW, Hex Washer Hd, Plastite, 1/4-20 x 1
15 1713847 1 KNOB
16 1923683 4 CAPSCREW, Hex. Washer Hd, Taptite 3/8-16 x 3/4
17 1667270 1 LEVER ASSEMBLY
18 1921963 2 CAPSCREW, Hex Hd, 1/4-20 x 2
19 1667437 1 TUBE ASSEMBLY (Manual Steer Models Only)
20 1675789 2 FITTING, Hydraulic
21 1668883 1 TUBE ASSEMBLY (Manual Steer Models Only)
22 1668882 1 TUBE ASSEMBLY (Manual Steer Models Only)
23 1916964 2 LOCKWASHER, 1/4
24 1708007 2 CLAMP
25 1921961 1 CAPSCREW, Hex Hd, 1/4-20 x 1-1/4
26 108186 1 CLIP
27 1921319 7 WASHER, Plain, 1/4
28 1916622 2 NUT, Hex, Full, 1/4-20
29 1708009 1 CONTROL VALVE ASSEMBLY (See following 2 pages for service parts)
30 1718681 1 LINK, Connecting, #50
31 1919439 1 NUT, Hex Nylon Lock, 3/8-16
32 1960294 2 NUT, Hex Flange, Whiz Lock, 1/4-20
33 1924940 1 WASHER, Plain, 3/8
34 1667269 1 SUPPORT ASSEMBLY
35 1960032 1 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
36 1673700 1 CABLE ASSEMBLY
37 1667261 1 BELLCRANK
38 1667435 1 TUBE ASSEMBLY (Manual Steer Models Only)
39 1918447 1 PIN, Cotter, 3/32 x 3/4
40 923905 2 FITTING, Hydraulic (Manual Steer Models Only)
Footnotes:
Assembly Notes: Take specail care that no dirt or foreign material is allowed to enter hydraulic circuit during
assembly of fittings.
1. To install swivel fittings (Ref. No. 20), first lubricate the O-ring with light oil. Then turn swivel nut until O-
ring is seated. Turn fitting by hand to align with tube nut.
2. To install tubes, first align threaded fitting with tube nut. Then thread nut onto fitting and tighten. Hold fit-
ting and tuirn nut with wrench to seal joint.
