11 TP 400-2218-00-SV-SMA
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692796 Sov 18HP Hydro
1692798 Sov 18HP Hydro PS
1692845 918H, 18HP Hydro
1692847 918H, 18HP Hydro PS
1692849 2818H 18HP Hydro
1692852 2818H, 18HP Hydro PS
Engine, Exhaust & Drive Shaft Group — Kohler 18HP OHV
1 1708405 1 SHUT OFF VALVE
2 1708873 1 HEAT SHIELD ASSEMBLY
3 171252 1 CAP, Fuel Tank
4 172744 2 STRAP, Fuel Tank
5 171330 2 STRAP, Tank
6 1666275 1 TANK ASSEMBLY, Fuel (Includes Ref. 6, 7, 8, 9, 10)
7 1654930 1 BUSHING
8 1664460 1 FITTING
9 1960112 2 CLAMP, Hose
10 1717557 1 HOSE, Fuel, 15”
11 * 1 ENGINE, Kohler, 18 HP
12 1925125 1 WASHER, 15/32
13 1708764 1 CHOKE CONTROL
14 1708763 1 THROTTLE CONTROL
15 1960475 1 SETSCREW, 3/8-24 x 3/8
16 157427 1 KEY, Drive Shaft, 3/16 x 1-1/4
17 172264 1 FLANGE, Drive Shaft
18 1916950 8 NUT, Hex, Full, 3/8-16
19 1916965 12 LOCKWASHER, 3/8
20 157424 8 WASHER, Special
21 1920415 4 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
22 1708729 1 SHAFT ASSEMBLY, Drive
23 927794 1 RETAINING RING
24 1668637 1 COUPLING, Compression
25 1921972 4 CAPSCREW, Hex Hd, 3/8-16 x 2-1/2
26 176440 1 BUSHING
27 1920676 1 CAPSCREW, Hex Hd, 7/16-14 x 1
28 1918199 1 LOCKWASHER, 7/16
29 960477 1 COUPLING, Pipe, Straight
30 901489 1 NIPPLE, Pipe, 3/8 x 1
31 1708761 1 PIPE, Exhaust,Elbow
32 920426 1 WASHER, External Tooth, 3/8
33 1921971 4 CAPSCREW, Hex Hd, 3/8-16 x 1-3/4
34 1924856 2 CAPSCREW, Hex Hd, Taptite, 5/16-18 x 1/2
35 1920415 2 CAPSCREW, Hex Hd, 3/8-16 x 1-1/4
36 1679588 1 CAPSCREW, Hex Head, M8-1-1/4 20mm
37 1686655 1 MUFFLER, Exhaust
38 1712286 1 CLAMP, Exhaust
39 173026 1 COUPLING
Footnotes:
* See an authorized Kohler Dealer for service parts.
