Instructions for the Installer
7
2. DIMENSION REQUIREMENTS
CLEARANCE
MODEL A B C (5) G (3) I (4) L (1) M (2) N
C9GMXU
914 mm
36 ”
636 mm
25 ”
216 mm
8
1
/
2
”
912 mm
35
15
/
16
”
457 mm
18”
610 mm
24 ”
330 mm
13 ”
150 mm
5
15
/
16
”
1 min. when bottom of wood or metal cabinet is protected by not less than ¼ “ (0.64 cm) flame
retardant millboard covered with not less than No. 28 MSG sheet steel, 0.015” (0.4 mm) stainless
steel, 0.024” (0.6 mm) aluminium or 0.020” (0.5 mm) copper.
2 max. upper cabinet depth;
3 min. cabinet opening width;
4 upper cabinet to countertop;
5 min. clearance from the sides of range to side wall or other combustible material;
6 Junction box.
NOTE: Install with zero clearance sides and back.
Grounded outlet
Position within 11
7
/
8
” (300 cm) from the left
rear corner of the range.
Gas supply line
Position within 11
7
/
8
” (300 cm) from the
right rear corner of the range.
