Axle group – Snapper GC9520KW User Manual
Page 9
9
ITEM NO.
QTY.
PART #
DESCRIPTION
1
5
27192
LUG NUT 1/2-20, YZ
2
1
29617
FLW, .77 X 1.31 X .06 YZ
3
2
35602
BEARING 30MM X 62MM
4
1
58642
ASSY., COUPLING W/ LUBE FITTING*
5 1 58650
ASSEMBLY,
PLATE/SEAL
6 1 72960
REAR
WHEEL
HUB
7 1 72965
CVT
AXLE
SUPPORT
8 1 72975
AXLE,
CVT
9
1
90297
COTTER PIN,1/8 X 3/4 YZ
10 4 91299
HNYL,3/8-16,
YZ
11
1
91778
WOODRUFF KEY 808
12
4
92052
HHCS, 3/8-16 X 5.5 - YZ
13
1
92038
HEX NUT, 7/8-14, YZ
14
2
92045
SNAP RING, 30MM, HD
15
2
92046
FLAT WASHER, 1 3/16 X 1 5/8 X .06
AXLE GROUP
*NOTE: Lube fitting part number is 13864.
GROUNDS CRUISER UTILITY VEHICLE SERIES 0
MANUAL No. 06126
