Page 42 silex Setting Configuration Parameters
Part Number 40183-101
Command Description
SHOW GPIO SPECIAL Shows functional mode of GPIO lines
SET GPIO SPECIAL ENA/DIS
<GPIO #>
GPIO # = {1|2|3|4|5|6|7|8}
Sets GPIO special function mode
Example:
Local> show gpio special
GPIO Special Functions
-----------------------
GPIO #1 is special
GPIO #2 is normal
GPIO #3 is special
GPIO #4 is special
GPIO #5 is special
GPIO #6 is special
GPIO #7 is special
GPIO #8 is special
Local> set gpio special disable 1
Local> set gpio special enable 2
Local> show gpio special
GPIO Special Functions
-----------------------
GPIO #1 is normal
GPIO #2 is special
GPIO #3 is special
GPIO #4 is special
GPIO #5 is special
GPIO #6 is special
GPIO #7 is special
GPIO #8 is special
Table 26 GPIO Trigger Commands
Command Description
SHOW GPIO TRIGger Shows current GPIO trigger conditions and
corresponding TRAP number
SET GPIO TRIGger <trigger state> <GPIO #>
Trigger state = {1| 0 | dis}
GPIO # = {1|2|3|4|5|6|7|8}
Sets GPIO Trigger Condition
1: 0 to 1 transition
0:1 to 0 transition
Dis: Disable
Example:
Local> set gpio trig 1 1
