Page 34 silex Setting Configuration Parameters
Part Number 40183-101
Parameter Description Settings Default Setting
Ecport E-cable destination IP port number 9100 or set by user 9100
Restoring Factory Default Settings
The factory default settings can restored at any time. Simply perform a cold reset by pressing and holding
the module push button for more than five seconds.
Modify Basic Settings
To establish communication between the SX-550 module and a serial device, the settings must be
identical for both devices.
Changing Serial Settings
The serial settings, such as mode and baud rate or speed for both the SX-550 module and serial device
must be identical in order to communicate. You can change the serial settings using ExtendView
(recommended), the web browser interface, or the SX-550 module’s internal configuration console.
To change serial settings:
1. Using ExtendView, web browser interface or internal command console, click the Output Port tab.
The Output Port window displays.
Figure 16 Output Port Tab
2. Click Serial Settings. The Serial Settings window displays.
