Product Characteristics
4.5 SCALANCE X204-2
"Industrial Ethernet TP and Fiber Optic Networks"
manual
6GK1970-1BA10-0AA0
IE FC Stripping Tool 6GK1901-1GA00
IE FC blade cassettes 6GK1901-1GB00
IE FC TP standard cable 6XV1840 2AH10
IE FC TP trailing cable 6XV1840-3AH10
IE FC TP marine cable 6XV1840-4AH10
IE FC RJ-45 Plug 180 pack of 1 6GK1 901-1BB10-2AA0
IE FC RJ-45 Plug 180 pack of 10 6GK1 901-1BB10-2AB0
IE FC RJ-45 Plug 180 pack of 50 6GK1 901-1BB10-2AE0
C-PLUG 6GK1 900-0AB00
Note
The number of connected SCALANCE X Industrial Ethernet Switches influences the frame
propagation time.
When a frame passes through the devices of the SCALANCE X-100 and/or SCALANCE X-
200 product lines, it is delayed by the store and forward function of the switch:
- with a 64 byte frame length by approx. 10 µs (at 100 Mbps)
- with a 1500 byte frame length by approx. 130 µs (at 100 Mbps)
This means that the more devices of the SCALANCE X-100 and/or SCALANCE X-200
product lines that a frame passes through, the higher the frame propagation time will be.
4.5 SCALANCE X204-2
4.5.1 Components of the SCALANCE X204-2
What ships with the SCALANCE X204-2?
• SCALANCE X204-2 Device
• 2-pin plug-in terminal block
• 4-pin plug-in terminal block
• Product information
• CD
– Commissioning Manual
– PST Tool
Industrial Ethernet SCALANCE X-100 and SCALANCE X-200 Product Line
Commissioning Manual, 1,
4-35
