89
8. Appendix
The Relationship between the Resolution
and the Data Size
The relationship between the resolution and the data size is mutually contradic-
tory. When the resolution (dpi) is set to a high value, the scanning area becomes
smaller. Inversely, when the scanning area is set larger, the resolution becomes
lower.
When the network delivery scanner, e-mail and document server are used, the
relationship between the scanning resolution and the data size is shown below.
If the data size is too large, the message “Exceeded max. data capacity. Check the
scanning resolution.” appears on the control panel of the machine. Specify the
scan size and resolution again.
Limitation
❒ Depending on the image compression level, the maximum image size will be
limited.
❖ ❖ ❖ ❖ When the “Text”, “Text/Photo”, or “Photo” is selected as the Scan Type
All combinations up to A3/11”x17” (297mm
×432mm) and 600 dpi are possible.
❖ ❖ ❖ ❖ When “Gray Scale” is selected as the Scan Type
The possible scanning combinations corresponding to the amount of memory
installed are shown below.
❍: When equipped with 256MB total memory
✩: When equipped with 384MB total memory
100dpi 200dpi 300dpi 400dpi 600dpi
A3 ❍ ❍ ❍ ❍ ✩
B4 ❍ ❍ ❍ ❍ ✩
A4 ❍ ❍ ❍ ❍ ❍
B5 ❍ ❍ ❍ ❍ ❍
A5 ❍ ❍ ❍ ❍ ❍
B6 ❍ ❍ ❍ ❍ ❍
A6 ❍ ❍ ❍ ❍ ❍
A7 ❍ ❍ ❍ ❍ ❍
11x17 ❍ ❍ ❍ ❍ ✩
Legal(8 1 /
2
x14)
❍ ❍ ❍ ❍ ❍
8 1 /
2
x13
❍ ❍ ❍ ❍ ❍
Letter(8 1 /
2
x11)
❍ ❍ ❍ ❍ ❍
5 1 /
2
x8 1 /
2
❍ ❍ ❍ ❍ ❍
