6. Install wing nut figure I) assembly as follows.
Insert 16-18 and washer
from inside the deck. Place the cup (H) onto the
and install lockwasher and 16 nut.
(Figure 12 shows correct position the
(A, figure 6) onto and install the
16 locknut (D) flush with end of screen.
7. The belt retainer (A, 5) must be positioned
correctly. Loosen the nut(B) and position the leg(C)
so it is against the side of the idler arm (D). Then,
tighten the nut (B).
Figure 6.
A. Wing Nut
Belt Retainer
c. Pulley
Locknut,
Figure 5.
A. Belt Retainer
Nut
c .
Idler Arm
E. Notch
F. Spacer
G. Small Spacer
H.
Notch
8. Install the blower assembly (figure 5) onto mower
deck as follows. Note that the notch(E) will be placed
onto small spacer(G) on top of the strap. The blower
assembly spacer(F) will tit into the strap notch(H).
a. Slide the
and tighten the wing nut (A).
b. Push the belt 6) to provide slack
and install belt onto lower groove in pulley
(Rotate pulley while placing belt on.)
9. Place the deck drive belt in the upper groove of the
pulley (C, figure 6).
10. This completes installation of the blower assembly.
Install the tube and collection system by following
directions provided in this manual. To the
blower assembly, see “Operating Without Collection
System.”
