Figure 24.
A. Frame Rod
Frame
Maintenance
Clip
D. Support
Rod
A
WARNING
The cart is subject to wear and deterioration.
Check the frequently. Use approved
replacement cover.
The can be rinsed with a hose when dirty. A dirty
cover will inhibit the fast flow of grass clippings into the
cover. Do not leave grass
leaves in the for a long
period of time.
Operation’
A
WARNING
For safety reasons grass and debris to he
removed only after engine is shut off, key removed,
and all
moving parts
Before shut off remove key,
BEFORE OPERATION
Clear the lawn of all sticks, stones, wire debris
which may be caught or thrown by the mower blades.
Clean the tube with mild detergent (other products may
damage tube). The flow of grass can be seen through the
tube while moving.
Check grass condition. If wet, wait until later in the day.
If grass is wet plugging may occur.
For efficient bagging, air circulation under the mower
deck, through the chute and into the bag is very
important. For this reason, you should remove grass and
debris from underside of mower deck, discharge chute
and
The tube and elbow can be removed as an assembly for
cleaning.
INSTALLATION OF TRACTORS GRASS CHUTE
TO CART COLLECTOR
I Attach the hose to the blower housing
figure 25) and tighten with a screwdriver or wrench.
2.
the elbow (H, 22) onto the tube.
Figure 25.
A. Clamp
Hose
C. Wing Nut
OPERATION WITH CART COLLECTOR
A
WARNING
Shut the tractor’s engine off before attaching,
adjusting, disconnecting the collector. Be
the complete collector is in place before
operating the tractor’s mower.
A
WARNING
Do not tow the cart collector on slopes greater than
15 degrees. Mow up and down the face of slopes;
never the face of any slope.
