39-

Looking at the controls

See pages in ( ) for more details.

The recorder

1 END SEARCH button (7)
2 REC indicator (14)
3 DISPLAY button (14, 19)
4 Display window (14, 19)
5 DC IN 3V jack (at the rear) (6)
6 MODE button (17)
7 =/+ (search /AMS) button (7, 9)

8 LINE IN (OPTICAL) jack (6, 11)
9 MIC (PLUG IN POWER) jack (12)
0 MIC SENS switch (at the bottom) (12)
!¡ LINE OUT jack (20)
!™ DIGITAL MEGA BASS button (18)
!£ p/CHARGE button (7, 9, 27)

!¢ ( (play) button (7, 9)

!∞ Battery compartment (at the rear) (27)

!§ EDIT/ENTER button (21)
!¶ AVLS switch (at the bottom) (18)
!• SYNCHRO REC (synchro-recording)

switch (11)

!ª VOLUME +/– button (9)
@º T MARK button (21)
@¡ P (pause) button (7, 9)

@™ REC (record) switch (7)
@£ OPEN button (6)
@¢ HOLD switch (20)
@∞ CLOCK SET button (at the bottom)

(16)

@§ 2 (headphones)/REMOTE jack (8)

!º

!¡

!™

!£

!¢

!∞

!§

!¶

!•

!ª

@º

@¡

@™

@£

@¢

@∞

@§
