English
22
Remote control unit
1 Still image shooting button
2 Video clip recording button
3 SET button
4 Works the same as toggling
SET button to the left
5 Works the same as toggling
SET button up or pushing zoom
switch toward the [T] ([]]) side
6 Works the same as toggling
SET button to the right
7 Works the same as toggling
SET button down or pushing
zoom switch toward the [W]
([P]) side
8 CH button
9 MENU button
1 (inoperative)
2 (inoperative)
3 SET button
4 Works the same as toggling
SET button to the left
5 Works the same as toggling
SET button up
6 Works the same as toggling
SET button to the right
7 Works the same as toggling
SET button down
8 CH button
9 MENU button
* Operation shortcuts are not available from the remote control unit.
Cable adaptor
Docking station
terminal USB/AV terminal
* The dedicated component cable
(supplied) cannot be connected.
DC IN terminal
