2-46
2
Push down the pressure roller up/down lever.
3
Select “BASE” in the “SELECT PAPER” menu and press
the key.
4
Input the paper width and press the key.
5
Input the base point (print offset value for paper width
direction: origin point).
The previous setting value will be displayed.
PAPER WIDTH
*1372 mm
BASE POINT
*0000 mm
SELECT PAPER
ROLL/SHEET: BASE
Pressure roller up/down lever
The paper width detected at
previous time is displayed.
(Paper width input range: 290
to 1635 mm)
The base point set at previous
time is displayed.
The origin moves if either paper width or base point is set.
Print margin
Base point input value
Paper width input value
