3-45
Section 3 Operation Panel Menu Operations
- ADJUST 2-1: Prints the phase, left and right, and inter-head
position adjustment patterns of HEAD ADJ 2.
- ADJUST 2-2: Prints only the reciprocating adjustment
pattern of HEAD ADJ 2.
(2) Nozzle jetting position adjustment (Bk/Lm/Lc/Y/M/C) (L/R ADJ YY)
Adjusts the jetting position of nozzle.
Enter an adjustment value according to the head adjustment pattern.
YY: Ink color
Display order:
Bk -> Lm -> Lc -> Y -> M -> C
- Sign: +/-
- Value:-32 to +31, A to H (A=0/8, B=1/8...H=7/8)
(3) Head position adjustment (Lm/Lc/Y/M/C) (H-POS ADJ YY)
Adjusts the head position for the scanning direction.
Enter an adjustment value according to the head adjustment pattern.
YY: Ink color
Display order:
Bk -> Lm -> Lc -> Y -> M -> C
- Sign: +/-
- Value:-32 to +31, A to H (A=0/8, B=1/8...H=7/8)
#L/R ADJ YY
>+00&A
#H-POS ADJ YY
>+00&A
