Instructions for the user

5. DESCRIPTION OF CONTROLS

5.1 Front control panel

All the cooker controls and commands are on the front panel.

DESCRIPTION OF SYMBOLS

OVEN THERMOSTAT

REAR RIGHT-HAND
COOKING ZONE

OVEN FUNCTIONS

FRONT RIGHT-HAND
COOKING ZONE

FRONT LEFT-HAND
COOKING ZONE

FISH COOKING ZONE

REAR LEFT-HAND
COOKING ZONE

FRONT CENTRAL
COOKING ZONE

THERMOSTAT KNOB

Selection of cooking temperature is carried out
by turning the knob clockwise to the required
temperature, between 50° and 250°C.
The tell-tale light comes on to indicate that the
oven is warming up.

When it goes out it means that the required temperature has been
reached. Regular flashing means that oven temperature is being
constantly maintained at the programmed level.
