Tapped mounting hole
Bracket A
Bracket B
(8) Single-guide
type
Use the tapped holes in the bracket for installing an actuator of the single-guide type.
z Applicable model: Double-guide type RGD4
Type Tapped
hole
diameter
Tapped
depth
Tightening
torque
RA4 type
M5
8 mm
3.4 N-m
