6
4.4 Motor Straight Type (Coupling Type): Single-guide Type
z RCS2-RGS4C
Caution: The cable directly connected to the actuator is not robot cable even when ordered
with robot cable option. When designing, please be sure not to give repeated
bending loads to this cable. The robot cable is applicable only to the connecting
cables.
Rod side Motor side
Right
Left
Rod Rod cover
Cylinder tube
Head cover
Motor unit
Cable
Guide bracket
Guide bearing
Guide rod
