8
Front Motor side
Right
Left
Rod
Rod tip adapter
Aluminum frame
Motor housing
Connector box
Encoder cover
Pulley cover
The names of respective actuator parts are indicated below.
In this manual, the right and left are determined by viewing the actuator from the top and from the motor
side when the actuator is placed horizontally. “Front” indicates the opposite side of the motor.
4.6 Motor Straight Type (Coupling Type): No Guide
z RCS2-RA5C
4.7 Motor Reversing Type: No Guide
z RCS2-RA5R
