• 36 •

Connect the POSITIVE (RED) charger clip to the POSITIVE (POS, P, +) post of the battery.

7.3

Position yourself and the free end of the cable you previously attached to the NEGATIVE

7.4

(NEG, N, -) battery post as far away from the battery as possible – then connect the

NEGATIVE (BLACK) charger clip to the free end of the cable.
Do not face the battery when making the final connection. As stated in 7.4, face away

7.5

from the battery when connecting the negative clip to the cable.
Connect charger AC supply cord to electrical outlet.

7.6

When disconnecting the charger, always do so in the reverse order of the connecting

7.7

procedure and break the first connection while as far away from the battery as practical.
A marine (boat) battery must be removed and charged on shore. To charge it onboard

7.8

requires equipment specially designed for marine use.
GROUNDING AND AC POWER CORD CONNECTIONS

8.

RISK OF ELECTRIC SHOCK OR FIRE.

This battery charger is for use on either a nominal 120V,

8.1

50/60 Hz or a nominal 230V, 50/60 Hz circuit. (See the warning

label on the charger for the correct input voltage.) The charger

must be grounded to reduce the risk of electric shock. The plug

must be plugged into an outlet that is properly installed and

grounded in accordance with all local codes and ordinances.

The plug pins must fit the receptacle (outlet). Do not use with an ungrounded system.

8.2

Never alter the AC cord or plug provided – if it does not fit the outlet,

have a proper grounded outlet installed by a qualified electrician. An improper

connection can result in a risk of an electric shock or electrocution.
If the AC cord is damaged, it must be replaced by the manufacturer, its service agent or

8.3

other qualified person in order to avoid a risk of personal injury or property damage.
Recommended minimum AWG size for extension cord:

8.4

100 feet (30.5 meters) long or less - use a 14 gauge (2.5mm

2

) extension cord.

Over 100 feet (30.5 meters) long - use a 12 gauge (4mm

2

) extension cord.

ASSEMBLY INSTRUCTIONS

9.

It is important to fully assemble your charger before use. Remove all cord wraps and

9.1

uncoil the cables prior to using the battery charger. Follow these instructions for assembly.

PARTS

TOOLS NEEDED

(2) 10-32, thread cutting screws
(4) ¼-20, thread cutting screws
(4) Phillips head sheet metal screws
(2) wheels
(1) axle
(2) axle caps
(2) axle brackets
(1) handle
(1) foot

3/8" wrench (for mounting foot)
5/16" wrench (for mounting wheels)
hammer
screwdriver (flat blade)
screwdriver (Phillips)
