Schumacher BT-100 - Manual

WARRANTY CARD
SAVE ON POSTAGE! ACTIVATE YOUR WARRANTY ONLINE –
THE QUICK AND EASY WAY!
Go to www.batterychargers.com to register your product online.
(No internet access? Send in the completed warranty card.)
6 MONTH LIMITED
W
ARRANTY
PROGRAM
REGISTRA
TION
MODEL:
_____________________
DESCRIPTION:
________________________
This is the only express limited warranty
, and the manufacturer neither assumes
nor authorizes anyone to assume or make any other obligation.
There is no other
warranty
, other than what is described in the product owner
’s manual.
The warranty card should be submitted within 30 days of purchase.
The customer
must keep the ORIGINAL
receipt because it will be required for any warranty claims.
This warranty is not transferable. Send warranty card only
.
DO NOT SEND UNIT T
O THIS
ADDRESS FOR REP
AIR.
Mail this card to:
Schumacher Electric Corporation 801 Business Center Drive Mount Prospect, IL
60056-2179
Name
______________________________________________________________
Street Address
_______________________________________________________
City
________________________________
State
_________
Zip Code
_________
Phone
_____________________
Email
___________________________________
Store Name Where Purchased
___________________
Date of Purchase
_________
Store Location
____________________
UPC Number
________________________
Serial Number
______________________________________
(SEE PRODUCT)
For faster warranty activation, go to
www
.batterychargers.com
to register your product online.
0099001450-00
READ THE ENTIRE MANUAL BEFORE USING THIS PRODUCT.
FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY.
Model: BT-100
Battery Load Tester/Charging System Analyzer
For 6 and 12 Volt Batteries
OWNERS MANUAL
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS – This manual will show you how to use your
tester safely and effectively. Please read, understand and follow these instructions
and precautions carefully, as this manual contains important safety and operating
instructions.
WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS.
BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL OPERATION. FOR
THIS REASON, IT IS IMPORTANT THAT YOU FOLLOW THESE INSTRUCTIONS
EACH TIME YOU USE THE TESTER.
WARNING: Pursuant to California Proposition 65, this product contains
chemicals known to the State of California to cause cancer and birth defects
or other reproductive harm. Wash hands after handling.
• Read the entire manual before using this product. Failure to do so could result
in serious injury.
• Use the tester in a well-ventilated area.
• This tester is not intended for use by children.
• Do not expose the tester to rain or snow.
• Do not operate the tester if it has received a sharp blow, been dropped or
otherwise damaged in any way; take it to a qualified service person.
• Inspect the battery for a cracked or broken case or cover. If the battery is
damaged, do not use the tester.
• Do not disassemble the tester; take it to a qualified service person when
service or repair is required. Incorrect reassembly may result in a risk of fire or
electric shock.
• Follow these instructions and those published by the battery manufacturer and
the manufacturer of any equipment you intend to use in the vicinity of the
battery. Review the cautionary markings on these products and on the engine.
PERSONAL SAFETY PRECAUTIONS
• Wear complete eye protection and protective clothing when working near
lead-acid batteries. Always have someone nearby for help.
• Have plenty of fresh water, soap and baking soda nearby for use, in case
battery acid contacts your eyes, skin or clothing. Wash immediately with soap
and water and seek medical attention.
• If battery acid comes into contact with eyes, flush eyes immediately for at least
10 minutes and get medical attention.
• Neutralize any acid spills thoroughly with baking soda before attempting to
clean up.
• Remove all personal metal items from your body, such as rings, bracelets,
necklaces and watches. A lead-acid battery can produce a short circuit current
high enough to weld a ring to metal, causing a severe burn.
• Never smoke or allow a spark or flame in the vicinity of the battery or engine.
OPERATING INSTRUCTIONS
BATTERY TEST
IMPORTANT: During the first use of this tester, you will notice a little smoke
and/or a burning smell. This is normal and will stop after a short burn-in period.
Also, during regular use, the metal housing of the unit will get hot enough to
burn skin or cause property damage; carry by the handle. Neither of these
factors will affect the performance of your tester.
1. Turn off the ignition, all accessories and any loads.
2. Clean the battery terminals.
3. Clip the red clamp to the positive (POS, P, +) battery terminal.
4. Clip the black clamp to the negative (NEG. N, -) battery terminal.
6V BATTERY ANALYSIS
1. Read the meter and confirm the battery voltage is in the green “OK” area
(see illustration).
2. Press and hold the load switch “on” for a maximum of 10 seconds and read
the meter with the load still on. The needle should remain in the green area.
If it doesn’t, the battery is weak or bad.
CAUTION: To prevent overheating, allow tester to cool for 5 minutes before
depressing the load switch again, if further testing is required.
12V BATTERY ANALYSIS
1. Find the Cold Cranking Amps (CCA) range on the meter (see illustration)
that matches the CCA rating of the battery being tested.
2. Press and hold the load switch “on” for a maximum of 10 seconds and read
the meter with the load still on. Then, refer to Table 1 or the back of the tester.
CAUTION: To prevent overheating,
allow tester to cool for 5 minutes before depressing the load switch again, if
further testing is required.
