Mode Setting
1N mode
External VD interval
Tv [line]
625 (20.0 ms)
312 (9.98 ms)
208 (6.65 ms)
156 (4.99 ms)
Partial scanning setting
10th digit
0
2
3
4
First digit
0
6
6
0
Effective lines
X [line]
580 (18.6 ms)
267 (8.54 ms)
157 (5.02 ms)
101 (3.23 ms)
BLKG interval
Tb [line]
45 (1.44 ms)
45 (1.44 ms)
51 (1.63 ms)
55 (1.76 ms)
Frame rate
[frame/s]
50
100
150
200
2I mode
External VD interval
Tv [line]
312.5 (10.0 ms)
156 (5.00 ms)
104 (3.32 ms)
78 (2.50 ms)
Partial scanning setting
10th digit
0
1
1
2
First digit
0
3
7
0
Effective lines*
X [line]
287.5 (9.2 ms)
128 (4.10 ms)
72 (2.30 ms)
43 (1.38 ms)
BLKG interval
Tb [line]
25 (0.80 ms)
28 (0.90 ms)
35 (1.12 ms)
Frame rate
[frame/s]
100
200
300
400
32 (1.02 ms)
* The number of effective lines in the 2I mode indicates the number of lines output from the Video 1 and 2 connectors.
– Determine and input each value for the colored columns.
BLKG interval Tb = 15 + n (n stands for the partial scanning setting value. When the 10th digit is 1 and the first digit is 3, n=13. The maximum value of
n is 49, and the minimum value of Tb is 25. When Tb ≤25, the BLKG interval is 25H, the constant value.
Effective lines X = Tv – Tb
BLKG interval Tb = 15 + n (n stands for the partial scanning setting value. When the 10th digit is 2 and the first digit is 6, n=26. The maximum value of
n is 99, and the minimum value of Tb is 45. When Tb ≤45, the BLKG interval is 45H, the constant value.
Effective lines X = Tv – Tb
