Instructions for the User
10.5.3 Removing the self-cleaning liners
Remove all accessories from the inside of the oven and proceed as
follows:
1
Remove the side runners (fig.1);
2
Extract the side liners “F” and “G” (fig. 2);
3
Extract the back liner “A” after undoing the threaded ring-nut “C”
(fig. 2);
4
Replace the liners in their original positions.
10.6 Cleaning the door glazing
The glass in the door should always be kept thoroughly clean. Use
absorbent kitchen roll; remove stubborn dirt with a damp sponge and
ordinary detergent.
