For Machines Mfg. Since 8/09 Model SB1029 I N T R O D U C T I O N
Machine Specifications
Model SB1029
6" x 18" Surface Grinder
Product Dimensions:
Weight ........................................................................................................................................................................1912 lbs.
Length/Width/Height ............................................................................................................................ 66
1 ⁄
4
" x 47 5 ⁄
16
" x 67 3 ⁄
4
"
Footprint (Length/Width) ........................................................................................................................................28" x 26 1 ⁄
4
"
Shipping Dimensions:
Type .................................................................................................................................................................... Wooden Crate
Content ........................................................................................................................................................................ Machine
Weight .........................................................................................................................................................................2082 lbs.
Length/Width/Height ....................................................................................................................................... 53" x 45" x 79"
Electrical:
Required Power Source ...................................................................................................220V or 440V, Three-Phase, 60 Hz
Switch .................................................................................................................... Magnetic Contactor w/Thermal Overload
Switch Voltage .................................................................................................................................................................. 110V
Cord Length ........................................................................................................................................................................ 7
ft.
Cord Gauge ................................................................................................................................................................ 14 Gauge
Recommended Circuit Size ..........................................................................................................................................15 Amp
Plug ....................................................................................................................................................................................... No
Recommended Plug .......................................................................... L15-15 for 220V or Hardwire 440V w/Locking Switch
Motors:
Spindle Motor
Type, Speed, Cycle ................................................................................................ TEFC Induction, 3450 RPM, 60 Hz
Horsepower ........................................................................................................................................................... 1
1 ⁄
2
HP
Voltage ............................................................................................................................................................220V/440V
Prewired .................................................................................................................................................................. 220V
Phase ...........................................................................................................................................................Three-Phase
Amps .............................................................................................................................................................4.2/2.4 Amp
Number Of Speeds .........................................................................................................................................................1
Power Transfer ............................................................................................................................................ Direct Drive
Bearings ................................................................................................................... Shielded and Permanently Sealed
Oil Pump & Motor
Type .......................................................................................................................................................Electromagnetic
Power .................................................................................................................................................................25 Watts
Voltage ...............................................................................................................................................................110 VAC
Cycle .................................................................................................................................................................. 50/60 Hz
Oil Reservoir Width/Length/Depth .......................................................................................................... 11" x 13" x 2"
Oil Filter or Screen .............................................................................................................................................. Screen
Oil Reservoir Capacity ...................................................................................................................................... 5 Quarts
Recommended Oil ............................... Mobil Vacuoline 1405 or 1409, Shell Tonna 27 or 33, BP Energol HP 20-C
