Southbend 6" x 18" SURFACE GRINDER SB1029 - Manual (Page 14)

-12-
For Machines Mfg. Since 8/09 Model SB1029 P R E P A R A T I O N
Unpacking
This item was carefully packaged to prevent
damage during transport. If you discover any
damage, please immediately call Customer
Service at (360) 734-1540 for advice. You may
need to file a freight claim, so save the containers
and all packing materials for possible inspection
by the carrier or its agent.
Inventory
Main Inventory 1: (See Figure 4) Qty
A. Surface Grinder (Wheel Installed) ................ 1
Tool Box Inventory: (See Figure 5) Qty
B. Column Elevation Handwheel ...................... 1
C. Column Elevation Handwheel Crank ........... 1
D. Cast Iron Feet ................................................ 5
E. Tool Box .......................................................... 1
F. Dressing Tool Base ........................................ 1
G. Diamond-Tip Dressing Tool ........................... 1
H. Hub Puller ...................................................... 1
I. T-Bolt Set ....................................................... 1
J. Feet Studs ...................................................... 5
K. Standard Screw Driver #2 ............................. 1
L. 10-Pc Hex Wrench Set
(1.5, 2, 2.5, 3, 4, 5, 5.5, 6, 8, 10mm) ............... 1
M. Spindle Wrench 47mm .................................. 1
N. Spindle Wrench 27mm .................................. 1
O. Adjustable Wrench 8" .................................... 1
P. Balancing Spindle .......................................... 1
Figure 4. Main inventory.
A
B
C
Figure 5. Small parts inventory.
G
F E
D
J
K
P
L
I
H
M
N
O
