Appendix
98
9
Limitation
❒ There may be a difference in the size of the image when it is printed at the des-
tination.
❒ If you set an original larger than DLT/A3 on the exposure glass, only an area
of DLT/A3 is scanned.
Note
❒ Even if an original is correctly placed on the exposure glass or in the Docu-
ment Feeder, a margin of 3mm around each edge of the original may not be
sent.
❒ If the receiver uses paper narrower than the original, the image will be re-
duced to fit the paper width.
❒ The machine detects paper sizes in the following ways.
• When you set an original in the Document Feeder, an original narrower
than about 9.1" (230mm) is scanned as 8
1
/
2
" width.
An original wider than about 10.4" (263mm) is scanned as 11" width.
Widths between 9.1" and 10.3" are scanned as 10" width.
Originals up to 47" (1200mm) in length can be scanned.
• Refer to the table below for the sizes the machine can detect when you
place an original on the exposure glass. Because the machine scans in non-
standard size documents as one of the standard sizes, parts of the image
may be truncated depending on the length of the document. For how to set
non-standard size documents, see P.7 “Choosing the Area to be Scanned Your-
self (Irregular Scan Area)”.
-
-
-
-Maximum Scan Area
Memory Transmission/Immediate Transmission
*1
• From the Document Feeder: 11"
Ч17" / 297Ч432mm (W×L)
• From the exposure glass: 11"
Ч17" / 297Ч432mm (W×L)
*1
In the immediate transmission, the maximum scan area varies according to the reso-
lution.
Length
width
∼12.5"
12.5"
∼ 13.5"
13.5"
∼
∼7.9"
not detected
8
1
/
2
"
×13"L
not detected
7.9"
∼ 8.9"
LT
L
8
1
/
2
"
×13"L
8
1
/
2
"
×14"L
8.9"
∼
LT
K
not detected
11"
×17"L
