Motor Type: ...................................................... TEFC Capacitor Start Induction
Motor: .............................................. 1⁄2 HP, 110V, 5 Amp., Single-Phase ⁄ 60 Hz
RPM: .............................................................................................. 1725
Power Transfer: ........................................................................ V-Belt Drive
Bearings: ................................................... Shielded & Lubricated Ball Bearings
Switch: ............................................ Toggle ON/OFF Switch, w/ Safety Lock Key
Spindle Travel: .................................................................................3-1⁄4''
Maximum Distance, Spindle to Base: ......................... W1669 = 15-1⁄2,'' W1670 = 49''
Maximum Distance, Spindle to Table: .................... W1669 = 9-1⁄4,'' W1670 = 31-1⁄2''
Overall Height: ..............................................W1669 = 31-1⁄2,'' W1670 = 64-1⁄2''
Head Tilt: .......................................................................45° Left, 90° Right
Table Tilt: ....................................................................... 90° Left and Right
Table Rotation: .................................................................................. 360°
Spindle Taper: ...................................................................................JT-33
Swing: ............................................................................................... 34''
Chuck Size: ..........................................................5⁄8'' (1-13mm JT-33), Keyed
Speeds: ........................................................................... 5, Belt Controlled
Range of Speeds: ...................................................550, 880, 1570, 2490, 3470 RPM
Drilling Capacity: ..........................................................1⁄2'' Diameter in Steel
Approximate Shipping Weight: .......................... W1669 = 100 lbs., W1670 = 150 lbs.
Specifications
INTRODUCTION
