MAINTENANCE
-29-
PARTS
.REF. PART.#. .DESCRIPTION
8 X1669008 GEAR
9 XPR16M EXT RETAINING RING 9MM
10 XPN03M HEX NUT M8-1.25
11 X1668019 CLAMP BOLT M10-1.5 X 30
15 X1669015 KNOB BOLT M8-1.25 X 16
16A X1669016A MOUNT PLATE N/S
16A-1 X1669016A-1 MOTOR PLATE N/S
19 X1669019 MOTOR 1 ⁄
2
HP, 110V
19-1 X1669019-1 S. CAPCTR 150MFD/125VAC
19-2 X1669019-2 CAPACITOR COVER
19-3 X1669019-3 MOTOR FAN
19-4 X1669019-4 FAN COVER
19-5 XPS54M PHLP HD SCR M4-.75 X 6
19-6 XPW05M FLAT WASHER 4MM
20 X1669020 PULLEY COVER
21 X1669021 MOTOR PULLEY
22 X1669022 V-BELT 0-1480
23 X1669023 UNTHREADED FEMALE KNOB
24 X1669024 LOCK PIN ASSEMBLY
25 X1669025 SPINDLE PULLEY
26 X1669026 DRIVE SLEEVE
27 XPR23M INT RETAINING RING M40
28 XP6203 BEARING 6203
28A X1669028A SPACER
30 X1669030 LEVER
31 XPLN08 LOCK NUT 1 ⁄
2
"-20
32 X1668024 SPRING COVER
32-1 X1668025 RETURN SPRING
33 X1669033 HORIZONTAL COLUMN
33-1 X1669033-1 HORIZONTAL COLUMN RACK
34 X1669034 HEADSTOCK
35 XPSW09 SWITCH AND KEY
35-1 XPSW09-1 SWITCH KEY
36 XPSS02 SET SCREW 5 ⁄
16
"-18 X 3 ⁄
8
"
37 XPS22 PHLP SCREW 10-24 X 5 ⁄
8
"
38 X1669038 SWITCH BOX
38-1 X1669038-1 SWITCH MOUNTING PLATE
39 X1669039 RUBBER WASHER
40 X1669040 QUILL SHAFT
41 XP6202 BEARING 6202
42 X1669042 SPINDLE JT#33
43 X1669043 CHUCK KEY
.REF. PART.#. .DESCRIPTION
44 X1669044 1 ⁄
2
" CHUCK 1-16MM JT#33
45 X1668031 COLLAR
45A-1 X1668031A DEPTH STOP ROD N/S
45A-2 X1669045A-1 DEPTH STOP ROD BRACKET
45A-3 X1668031A-6 DEPTH STOP MOUNT
46 X1668030 FEED SHAFT
47 X1668033 FEED COLLAR
48 X1669048 HANDLE AND KNOB
49 X1669049 DEGREE SCALE
50 XPR03M EXT RETAINING RING 12M
51 XP6201 BEARING 6201
52 X1669052 POWER CORD
53 X1669053 set screw
54 XPS07 PHLP SCREW 1 ⁄
4
"-20 X 3 ⁄
8
"
56 X1669056 RIVET
59 X1669059 SPECL SET SCR 5 ⁄
16
"-18 X 1"
60 XPN02 HEX NUT 5 ⁄
16
"-18
62 X1669062 LABEL
63 X1669063 WIRE STRAP
64 XPS06 PHLP SCREW 10-24 X 3 ⁄
8
"
65 X1669065 MOTOR SWITCH CORD
66 X1669066 SPEED CHART
75 X1669075 SAFETY LABEL
76 X1669076 LOCKING GIB
77 XPW01M FLAT WASHER 8MM
79 XPW06M FLAT WASHER 12MM
81 XPB09M HEX BOLT M8-1.25 X 20
85 X1669085 Safety goggles LABEL
86 X1669086 LONG HAIR SAFETY LABEL
87 XPAW03M HEX WRENCH 3MM
88 XPAW05M HEX WRENCH 5MM
89 XPHTEK7 SELF TAP SCREW #8 X 3 ⁄
8
"
93 X1669093 RUBBER WASHER 8MM
94 X1669094 GUIDE ROD 16 X 30MM
102 XPN02M HEX NUT M10-1.5
103 XPLW06M LOCK WASHER 10MM
104 XPW03M FLAT WASHER 6MM
105 XPS68M PHLP HD SCR M6-1 X 10
106 XPN03M HEX NUT M8-1.25
107 XPN02M HEX NUT M10-1.5
108 XPSB14M CAP SCREW M8-1.25 X 20
W1669,.W1670.Parts.List
