MAINTENANCE
-33-
PARTS
.REF. PART.#. .DESCRIPTION
1 X1670001 BASE
3 XPB31M HEX BOLT M10-1.5 X 40
4A X1670004A W1670 RACK
5A X1670005A W1670 COLUMN
7 X1668010A GEARED TBL BRKT N/S
7-1 X1668010A-2 COMPLETE TBL BRKT ASSY
7-2 X1669007-2 SCALE
11 X1668019 LEVER BOLT M10-1.5 X 30
13 X1670013 HORR. COLUMN BRKT
56 X1669056 RIVET
70 X1668010A-3 AXLE
71 X1668012 WORM PINION
72 X1668016 LIFT HANDLE
73 XPSS01M SET SCREW M6-1.0 X 10
.REF. PART.#. .DESCRIPTION
74 X1668015 WORM GEAR
80 X1668008 COLUMN RING
83 X1670083 TABLE
84 X1668010A-1 COLUMN SUPPORT ARM N/S
84-1 X1669084-1 SCALE
84A X1670084A TABLE SUPPORT ARM
92 X1668013 CLAMP BOLT M12-1.75 x 50
93 X1670093 HEX BOLT M8-1.25 X 125
94 XPN01M HEX NUT M6-1.0
95 X1668111B SPECIAL PIN
96 X1670096 HEX BOLT 5 ⁄
8
"-13 X 1 1 ⁄
2
"
97 XPW14 FLAT WASHER 5 ⁄
8
"
98 XPWN02M WING NUT M8-1.25
101 X1668152 SPECIAL WRENCH
W1670.Parts.List
