Formats and Limitations of Outputs 117
A
ppe
ndix
e
s
Output formats in clip playback mode
(Media mode)
Analog component signals from the
COMPONENT OUT connector are output in the
format shown below according to the video
format of the playback clip and the “YPbPr/SDI
Out Select” setting (HD or SD) of the VIDEO
SET menu.
The SDI OUT connector outputs serial digital
signals of the same format converted from the
analog component signals fed from the
COMPONENT OUT connector.
Note
No signal is output from the A/V OUT connector
when “YPbPr/SDI Out Select” of the VIDEO
SET menu is set to “HD” or “SD.”
When the frame rate setting of the video format
is 59.94i/59.94P/29.97P/23.98P
1) No signal is fed from the SDI OUT connector.
2) The actual frame rate of the output signal is 1.001
times of the value shown in the table. Some frame may
be repeated when converting the frame rate.
When the frame rate setting of the video format
is 50i/50P/25P
1) No signal is fed from the SDI OUT connector.
2) The actual frame rate of the output signal is 1/1.001 of
the value shown in the table. Some frame may be
deleted when converting the frame rate.
The outputs from the camcorder are limited by the VIDEO SET menu settings as follows. These
limitations are common to Camera mode and Media mode.
Clip format Output format
YPbPr Out
Select: HD YPbPr Out
Select: SD
1080/59.94i 1080/59.94i 480/59.94i
1080/29.97P 1080/29.97PsF 480/59.94i
1080/23.98P 1080/59.94i 480/59.94i
720/59.94P 720/59.94P 480/59.94i
720/29.97P 720/59.94P 480/59.94i
720/23.98P 720/59.94P 480/59.94i
1080/50i 1080/59.94i 1), 2) 480/59.94i 1)
1080/25P 1080/29.97PsF 1), 2) 480/59.94i 1)
720/50P 720/59.94P 1), 2) 480/59.94i 1)
720/25P 720/59.94P 1), 2) 480/59.94i 1)
Clip format Output format
YPbPr Out
Select: HD YPbPr Out
Select: SD
1080/59.94i 1080/50i 1), 2) 576/50i 1)
1080/29.97P 1080/25PsF 1), 2) 576/50i 1)
1080/23.98P 1080/50i 1), 2) 576/50i 1)
720/59.94P 720/50P 1), 2) 576/50i 1)
720/29.97P 720/50P 1), 2) 576/50i 1)
720/23.98P 720/50P 1), 2) 576/50i 1)
1080/50i 1080/50i 576/50i
1080/25P 1080/25PsF 576/50i
720/50P 720/50P 576/50i
720/25P 720/50P 576/50i
Limitations of Outputs
Menu settings i.LINK I/O Enable Disable Enable Disable Enable Disable
YPbPr/SDI Out Select HD HD SD SD Off Off
Outputs from
the output
connectors i.LINK(HDV) HDV No signal HDV No signal HDV No signal
SDI OUT No signal HD No signal SD No signal No signal
COMPONENT OUT HD HD SD SD No signal No signal
A/V OUT No signal No signal No signal No signal SD SD
