74_ web viewer
web viewer
NEXT: When this button is clicked, the next screen appears.
In SINGLE MODE, the channel numbers are sequentially switched from 1 to 16.
In QUAD MODE, the screens are changed like 1st 4 channels (1~4) 2nd 4 channels (5~8) 3rd
4 channels (9~12) 4th 4 channels (13~16). In NINE MODE, the screens are changed from 9 channels
(1~9) to 7 channels (10~16). In SIXTEEN MODE, the screen is refreshed.
If 16-channel DVR is connected, clicking “NEXT” in QUAD MODE is to change the screen as shown in the picture.
SAVING THE LIVE SCREEN ON THE PC
CAPTURE: Saves the current screen into a BMP or JPEG
fi le.
The default saving path is “C:\Program Files\Samsung\Dvr
Web Viewer\SnapShot\Live”. To change the saving path, click
)> button and then select the path you
want. For Windows Vista, the saving path is “C:\users\(user
ID)\AppData\LocalLow\Samsung\DVR Web Viewer\Snapshot\”
and it cannot be modifi ed.
The fi le is automatically named as following: “IP address_
Port number_YYMMDD_camera number_index”
Ex) 192.168.130.12_554_20070615_101530_01_00
PRINT: Prints out the selected screen out of the currently
displayed live screens. It also prints the IP address, time,
camera number and the current event status together.
•

•
M 

•
(CH1 to CH4)
16-channel DVR
(CH5 to CH8) (CH9 to CH12) (CH13 to CH16)
