English _33

LIVE
EVENT MONITORING
This will display the channel in sync with a specifi c event (Sensor/Motion/Video Loss) if it occurs.
In “Monitor>Event Display”, set the event monitoring to ON/OFF and specify the event display time.
(Page 46)
If multiple events occur simultaneously, the screen will switch to a split mode.
- 2~4 events: 4-split mode
- 5~9 events: 9-split mode
- 10~16 events: 16-split mode
If the second event occurs within the set time of <Event Display>, the fi rst event will last until the second
one is terminated. (Page 46)
Ex : If you set to 5 seconds, and only one event occurs in CH 1.
Ex : If you set to 5 seconds, and the second event occurs in CH 2 within the set time after the fi rst event
occurred in CH 1.
Press the [ALARM] button to reset the alarm settings and to release the event mode.
If an alarm activates in the condition you have set the event record, and pre/post alarm times, the event record will
be performed.
This will also apply to the SPOT OUT monitor.
•
•


M 


CH1
Event occurrence 5 seconds
Stop alarm
CH1 CH2
CH1
Event occurrence 4 seconds 9 seconds
Stop alarm
