Model W1828 (For Machines Mfg. Since 4/11)
-11-
SE
TU
P
Keep machine disconnected from
power until instructed otherwise.
SETUP
This machine has been carefully packaged for safe
transportation. If you notice the machine has been
damaged during shipping, please contact your authorized
Shop Fox dealer immediately.
Unpacking
The following is a description of the main components
shipped with the Model W1828. Lay the components out
to inventory them.
Note: If you can't find an item on this list, check the
mounting location on the machine or examine the
packaging materials carefully. Occasionally we pre-install
certain components for safer shipping.
Box Inventory (Figure 3) Qty
A. Disc Sander Assembly .....................................1
B. Sandpaper Disc 12" 80 Grit ...............................1
C. Miter Gauge Assembly ....................................1
Inventory
The following are needed to complete the setup process,
but are not included with your machine.
Description Qty
• Safety Glasses ..............................................1
• Cleaner/Degreaser ............................ As Needed
• Disposable Shop Rags ......................... As Needed
• Dust Collection System ...................................1
• Dust Hose 2" ...............................................1
• Dust Hose Clamp 2" .......................................1
• Adapter 4" x 2" (Optional) ...............................1
• Dust Hose 4" (Optional) ...................................1
• Dust Hose Clamp 4" (Optional) ..........................1
• Mounting Hardware ........................... As Needed
Needed for Setup
Figure 3. Shipping inventory.
A
B
C
