-41-
Df[\cN(/)0D]^%J`eZ\0&((
G8
I
K
J
GXikjC`jk
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 X1829001 TABLE 49 X1829049 ALIGNMENT PIN
2 X1829002 FENCE 50 X1829050 PUSH BLOCKS
2A X1829002A FENCE ASSEMBLY 51 X1829051 PADDLE SWITCH
3 X1829003 FENCE PLATE 52 XP6000ZZ BALL BEARING 6000ZZ
4 X1829004 FENCE TILTING HANDLE 53 XPSS01M SET SCREW M6-1 X 10
5 XPW01M FLAT WASHER 8MM 54 XPCAP26M CAP SCREW M6-1 X 12
6 X1829006 RIGHT LINK 55 XPLW03M LOCK WASHER 6MM
7 X1829007 LEFT LINK 56 XPW03M FLAT WASHER 6MM
8 X1829008 PLATE SHAFT 57 XPS09M PHLP HD SCR M5-.8 X 10
9 X1829009 BRACKET SHAFT 58 XPW02M FLAT WASHER 5MM
10 X1829010 LIMIT PLATE 59 XPCAP17M CAP SCREW M4-.7 X 10
11 X1829011 BLOCK 60 X1829060 TAP SCREW M6 X 12
12 X1829012 SHAFT 61 XPS26M PHLP HD SCR M6-1 X 20
13 X1829013 FENCE BRACKET 62 XPLW04M LOCK WASHER 8MM
14 X1829014 FENCE SLIDING HANDLE 63 XPCAP14M CAP SCREW M8-1.25 X 20
15 X1829015 FENCE SUPPORT 64 XPCAP02M CAP SCREW M6-1 X 20
16 X1829016 LOCKING PLATE 65 XPB94M HEX BOLT M5-.8 X 25
17 X1829017 TABLE PIN 66 XPN06M HEX NUT M5-.8
18 X1829018 FRAME PIN 67 XPCAP83M CAP SCREW M6-1 X 55
19 X1829019 BRACKET 68 XPN01M HEX NUT M6-1
20 X1829020 INFEED TABLE 69 XPCAP07M CAP SCREW M6-1 X 30
21 X1829021 TABLE FRAME 70 X1829070 RIBBED V-BELT 171J5 NK
22 X1829022 SUPPORT PLATE 71 XPN03M HEX NUT M8-1.25
23 X1829023 KNOB 72 XPB20M HEX BOLT M8-1.25 X 35
23-1 X1829023-1 KNOB BOLT 73 X1829073 SHAFT RETAINER M10
24 X1829024 MOTOR 2HP UNIVERSAL 74 XPEC09M E-CLIP 6MM
24-1 X1829024-1 CARBON BRUSH SET 75 XPSS28M SET SCREW M6-1 X 30
24-2 X1829024-2 BRUSH COVER 76 XPCAP07M CAP SCREW M6-1 X 30
24-3 X1829024-3 RING TERMINAL 77 XPSS29M SET SCREW M6-1 X 35
24-4 X1829024-4 SPADE TERMINAL 78 XPSS11M SET SCREW M6-1 X 16
25 X1829025 MOTOR PULLEY 79 XPS05M PHLP HD SCR M5-.8 X 8
26 X1829026 MOTOR MOUNTING PLATE 81 XPS38M PHLP HD SCR M4-.7 X 10
27 X1829027 CORD CLAMP 82 XPTLW01M EXT TOOTHED WASHER 4MM
28 X1829028 COMPRESSION SPRING 83 XPLW01M LOCK WASHER 5MM
29 X1829029 BLADE GUARD 84 X1829084 WIRE NUT
29-1 X1829029-1 RUBBER BUMPER 85 XPR03M EXT RETAINING RING 12MM
30 X1829030 TORSION SPRING 86 XP6201ZZ BALL BEARING 6201ZZ
31 X1829031 PIN 87 X1829087 STR SNAP-IN STRAIN RELIEF 5/8"
33 X1829033 SHAFT 89 X1829089 POWER CORD 16G 3W 5-15 72"
34 X1829034 CUTTERHEAD 90 X1829090 SPADE TERMINAL
35 X1829035 KNIVES 2-PC SET 6 x 7/8 x 3/32" 91 X1829091 RING TERMINAL
36 X1829036 KNIFE CLAMP 92 X1829092 FAN RIBBED V-BELT V1.25-7A
37 X1829037 DRIVE PULLEY 93 X1829093 DUST PORT
39 X1829039 JACK SCREW M4-.7 X 10 94 XPW02M FLAT WASHER 5MM
40 XPCAP115M BUTTON HD CAP SCR M6-1 X 16 95 X1829095 DUST COLLECTION BAG
41 X1829041 FAN PULLEY 96 XPN01M HEX NUT M6-1
42 X1829042 SPACER 97 X1829097 CLAMP 60MM
43 X1829043 FAN SHAFT 98 X1829098 SOLID PIN 4.5 X 20MM
44 X1829044 CHIP BLOWER MOUNTING PLATE 99 X1829099 CLAMP HANDLE
44-1 XPR17M EXT RETAINING RING 26MM 100 X1829100 SWING BOLT M6-1 X 50
45 X1829045 IMPELLER 102 XPAW06M HEX WRENCH 6MM
46 X1829046 CHIP EXHAUST 103 XPAW04M HEX WRENCH 4MM
47 X1829047 CHIP COLLECTOR 104 X1829104 BASE
48 X1829048 BASE BOTTOM 105 X1829105 SWITCH MOUNTING PLATE
