-14-
Df[\cN(/)0D]^%J`eZ\0&((
J<
K
L
G
8jj\dYcp
KfXjj\dYc\k_\af`ek\i#[fk_\j\jk\gj1
(% DISCONNECT JOINTER FROM POWER!
)% Use two of the included M8-1.25 x 20 cap screws and
lock washers 8mm to attach the fence support to the
jointer bed, as shown in
=`^li\0.
*% Insert the locking plate assembly into the fence
support, positioning it so the two pins are against
the bottom edge of the fence support, as shown in
=`^li\('.
+% Secure the locking plate in position with the fence
sliding handle, as shown in =`^li\((.
,% Use the remaining four M8-1.25 x 20 cap screws and
8mm lock washers to attach the fence to the fence
bracket assembly, as shown in
=`^li\().
=`^li\0% Attaching the fence support.
=`^li\('% Inserting the locking plate.
=`^li\((% Installing fence sliding handle.
=`^li\()% Attaching the fence bracket
assembly to the fence.
Fence
Support
Locking
Plate Pins
Locking Plate
Assembly
Locking Plate
Assembly
Fence Sliding
Handle
Bracket
Assembly
Cap
Screws
Fence
Cap Screws
