-33-
Df[\cN(/)0D]^%J`eZ\0&((
J
M
@:<
D8B< JLI< k_Xk pfli dXZ_`e\ `j
legcl^^\[ [li`e^ Xcc j\im`Z\ gifZ\$
[li\j @] k_`j nXie`e^ `j `^efi\[# j\i`$
fljg\ijfeXc`ealipdXpfZZli%
KffcjE\\[\[ Hkp
Flathead Screwdriver ..........................................1
Wrench 8mm .....................................................1
Wrench 10mm ...................................................1
J\kk`e^0'—=\eZ\8e^c\Jkfg
(% DISCONNECT THE JOINTER FROM POWER!
)% Position the fence over the bed and tighten the
sliding handle, loosen the fence tilting handle.
*% Press the forward tab of the limit plate into the rear
slot of the limit block.
+% Tilt the fence as far as it will go towards 90º
(perpendicular to the table) until it hits the limit
block shaft. Tighten the fence tilting handle.
,% Use a square to check the angle of the fence, as
shown in =`^li\++.
— If the fence is perpendicular to the table, the
90º stop is set correctly; no additional steps are
necessary. Proceed to set the 45º inward and 45º
outward stops (see Page 34).
— If the fence is not perpendicular to the table,
adjust the 90º stop by doing Jk\gj-Æ0.
-% Loosen the fence tilting handle, bring the fence
to 90º with the square set against the fence, then
tighten the handle.
Note:B\\gk_\c`d`kgcXk\kXY`ek_\i\Xijcfkf]
k_\c`d`kYcfZb%
.% Loosen the jam nut (located at the rear of the limit
block shaft).
/% Using a flathead screwdriver, turn the limit block
shaft until it hits the fence.
0% Tighten the jam nut. The 90º stop is now set.
J\kk`e^=\eZ\8e^c\Jkfgj
=`^li\++% Checking the 90º stop.
=`^li\+*% Fence stop parts identification.
Limit Plate
Tab
Inward Stop
Limit Block
Rear Slot
Jam
Nut
Limit Block
Shaft
This section provides instructions for setting the fence
angle stops precisely at 90°, 45° inward, or 45° outward.
Note:Kf\ejli\XZZliXk\i\jlckjn_\e\[^\af`ek`e^#
Z_\Zbk_\XZZliXZpf]k_\j\j\kk`e^j]i\hl\ekcpdfek_cp
XkXd`e`dld Xe[i\$X[aljkk_\d`]e\Z\jjXip%
