56
Instructions for the Installer
12.2 Removing the door
12.2.1 With type 1 mobile levers
With the door completely open, lift the levers A of the two hinges until
they touch the hinges B and take hold of the two sides of the door with
both hands close to the hinges themselves. Raise the door to an angle of
about 45° and remove it. If the hinges have not locked, repeat the
operation, raising the levers and keeping the door slightly raised. To
reassemble, fit the hinges B into their grooves, then lower the door into
place, ensuring that it remains fitted into the grooves C, then lower the
levers A..
1)
12.2.2 Removing doors with pins
Open the door completely and insert the pins (supplied) into the holes
from the inside. Close the door to an angle of about 45° and lift it off. To
reassemble, fit the hinges into their grooves, then lower the door into place
and extract the pins. If you should lose the pins, two screwdrivers can also
be used.
12.3 Removing the inside glass with the door cold
The glass in the door should always be kept thoroughly clean. For easier
cleaning, the door glazing can be fully removed by proceeding as
described below. After opening the door and locking it in place as
described in point “12.2 Removing the door”, remove the three panes of
glass. They are all removed in two stages: first extract the pane from the
guide "A" (see detail) by sliding it towards you and lifting it slightly, then
also free it from the guide "B". If the door should close during these
operations, simply relock one of the hinges as described in point "12.2
Removing the door". The panes of glass can now be washed separately.
