Monaco Technical Reference
Spectrum Signal Processing
Connector Pinouts
72
Part Number 500-00191
Revision 2.00
Table 24 PEM 2 Connector Pinout
Pin #
Signal
Pin #
Signal
1
GND
2
GND
3
CLKX1
4
ED0
5
FSX1
6
ED1
7
DX1
8
ED2
9
DR1
10
ED3
11
FSR1
12
ED4
13
CLKR1
14
ED5
15
GND
16
ED6
17
CLKS1
18
ED7
19
RSVD
20
GND
21
/PEM_CE2
22
ED8
23
RSVD
24
ED9
25
/HOLD
26
ED10
27
/HOLDA
28
ED11
29
RSVD
30
ED12
31
EA20
32
ED13
33
EA21
34
ED14
35
RSVD
36
ED15
37
+3.3V
38
+5V
39
+3.3V
40
+5V
41
/BE0
42
DMAC0
43
/BE1
44
DMAC1
45
/BE2
46
DMAC2
47
/BE3
48
+12V
49
/SDRAS
50
-12V
51
/SDCAS
52
/PEM_INT2
53
/SDWE
54
RSVD
55
GND
56
GND
57
PEM_TIMER
58
RSVD
59
GND
60
SDA10
