PCI Interface
Part Number 500-00191 33
Revision 2.00
6 PCI Interface
The Hurricane chip provides the interface between the Global Shared SRAM on the
Global Shared Bus and the PMC site which supports a 32 bit, 33 MHz PCI bus. Although
the DSPs cannot directly master the PCI bus, the Hurricane’s DMA controller provides
flexible data transfer between the Global Shared Bus SRAM and the PMC.
Embedded PCI buses require Hurricane PCI configuration cycle generation.
Pre-emptive arbitration is not used. If a node requests the Global Shared bus when the
bus is not currently in use, then it will be granted the bus. It is up to the bus ownership
timers of the Hurricane and PMC devices to prevent bus hogging.
PMC modules can directly master the Global Shared SRAM.
The memory map of the Monaco seen by a PMC module is shown in the following
figure.
PCI Offset Address Access
0000 0000h
Global Shared SRAM
001F FFFFh
0020 0000h
Hurricane Control Registers
002F FFFFh
0030 0000h
Reserved
003F FFFFh
Figure 10 PCI Memory Map
6.1. Hurricane Configuration
Before the PMC site can be accessed, the Monaco initialization software must configure
the Hurricane registers with the values shown in the following table. Only the indicated
values should be initialized, all other values should be left alone. As can be seen, these
registers can be accessed from a ‘C6x, the PMC’s PCI bus, and a host on the VME bus.
