Spectrum Signal Processing Monaco Technical Reference
Introduction
Part Number 500-00191 7
Revision 2.00
1.8. Jumper settings
Table 2 Jumper Settings
Jumper Description IN OUT
JP1 Pins 1-2 VME A24 slave interface base address bit A23 0 1*
JP1 Pins 3-4 VME A24 slave interface base address bit A22 0* 1
JP1 Pins 5-6 VME A24 slave interface base address bit A21 0* 1
JP1 Pins 7-8 VME A24 slave interface base address bit A20 0* 1
JP1 Pins 9-10 VME A24 slave interface base address bit A19 0* 1
JP1 Pins 11-12 VME A24 slave interface base address bit A18 0* 1
JP1 Pins 13-14 VME A24 slave interface base address bit A17 0* 1
JP2 Node A boot mode PEM HPI*
JP3 Node B boot mode PEM HPI*
JP4 Node C boot mode PEM HPI*
JP5 Node D boot mode PEM HPI*
JP7 Node A Serial Port 1 Routing VME P2 PEM*
JP8 Node B Serial Port 1 Routing VME P2 PEM*
JP9 Node C Serial Port 1 Routing VME P2 PEM*
JP10 Node D Serial Port 1 Routing VME P2 PEM*
* Default position
Note: The default VME A24 slave interface base address is set to 80 0000h.
