Monaco Technical Reference Spectrum Signal Processing
PCI Interface
36 Part Number 500-00191
Revision 2.00
Hurricane
DSP Offset 'C6x
Address
PCI Bus
Offset
Slave A32/A24
SCV64 Offset
Register Description Value Initialize
0x4F 0x016C 013C 0x0020 013C 0x0020 013C 0x0120 0100
0x50 0x016C 0140 0x0020 0140 0x0020 0140 BAR0 Shadow Register 0xFF00 0000 Y
6.2. Hurricane Implementation
The Hurricane PCI-to-DSP Bridge Data Sheet should be read in order to understand
how it is used with the Monaco board.
On the DSP port of the Hurricane, only bank 0 is used to access the Global Shared Bus.
All other Hurricane DSP banks are unused.
There are two devices on the PMC site’s PCI bus: the Hurricane chip and the PMC
device. The IDSEL line from each of the two PCI devices is connected to the following
Address/Data lines:
PCI Device IDSEL Connection
Hurricane AD16
PMC Module AD17
