Monaco Technical Reference Spectrum Signal Processing
Registers
54 Part Number 500-00191
Revision 2.00
DSP~LINK3 Register
Address: 016D 8018h
D31.. ..D8
Reserved
D7.. ..D2 D1 D0
Reserved ASTRB_EN DL3_RESET
Processor node A uses this register assert or release reset to the DSP~LINK3 interface its
local bus. It is also used to control the operation of DSP~LINK3 standard fast accesses.
DL3_RESET
•
Setting this bit (D0) to “1” asserts reset to the DSP~LINK3.
•
Setting this bit (D0) to “0” releases the DSP~LINK3 from reset.
Set to “1” upon reset. Application code must set it to “0” to release the
DSP~LINK3 from reset.
ASTRB_EN
•
Setting this bit (D1) to “1” enables ASTRB accesses to DSP~LINK3.
Accesses to the standard fast region when ASTRB_EN is set will be
/ASTRB accesses.
•
Setting this bit (D1) to “0” disables ASTRB accesses to
DSP~LINK3. Accesses to the standard fast region when ASTRB_EN
is cleared will be /DSTRB accesses.
Set to “0” upon reset.
This read/write register is not accessible from nodes B, C, or D.
