System Anl 6
Default setting
Co1 -> Fb00 = OFF (without RF1)
Co1 -> Fb01 = OFF (without RüF1)
Co1 -> Fb02 = ON (with AF1)
Co2 -> Fb00 = OFF (without RF2)
Co2 -> Fb01 = OFF (without RüF2)
Co2 -> Fb02 = OFF (without AF2)
Co3 -> Fb00 = OFF (without RF3)
Co3 -> Fb01 = OFF (without RüF3)
Co3 -> Fb02 = OFF (without AF3)
Co5 -> Fb00 = ON (with VFsek)
34
EB 5179 EN
Systems
BE
BA
AE
RK
AF3 AF2 AF1
VF
sek
UP1
UP2 RK
HK1
RF1 VF1
RüF1
RK
HK2
RüF2
RF2
VF2 UP3
RK
HK3
RüF3
RF3
VF3
